MB9 Catwalk Tiny House
2
1
1
1
36Model Features
MB9 Catwalk Tiny House is an innovative tiny house model featuring a specially designed catwalk detail and two loft levels that allow full standing height. This unique design maximizes both functionality and comfort, offering a truly elevated tiny living experience.
The MB Tiny House with catwalk has been developed by carefully optimizing the chassis and interior dimensions to remain fully compliant with tiny house regulations, while providing maximum comfort in the loft areas. Thanks to this smart engineering approach, the interior feels spacious and open, and everyday usability is significantly enhanced.
| Overall Dimensions | 9.00 x 2.55 m + 2 Loft |
| Chassis and Axle | Chassis: ST37 steel quality main chassis with double 100 NPU beams, ST37 steel intermediate cross members to prevent bending, and ST37 upper chassis. Axle Assembly: Dual axle system with brake system, 3,500 kg load capacity, braked coupling, 4 stabilizer jacks, 1 front support jack, side marker lights, tail lights, 4 tires and rims. |
| Frame | Galvanized Steel Profiles |
| Insulation | Rock Wool + XPS + Moisture Barrier + EPDM Membrane |
| Exterior Cladding | Thermowood Pine + Aluminum Panels |
| Interior Cladding | Laminated Wood Cladding or Birch Plywood |
| Flooring | Laminate Flooring + 18 Mm Plywood + Rock Wool + XPS + Polycarbonate |
| Roof | Plywood + Rock Wool + XPS + EPDM Membrane + Aluminum Panels |
| Doors and Windows | Thermally Insulated Tempered Double-Glazed Glass + Aluminum Framed Windows And Doors |
| Kitchen | MDF and Acrylic Cabinets + Solid Oak Kitchen Countertop + Butler Sink + Sink Tap + Faucet |
| Bathroom | SPC Wall Panels + Sink + Sink Tap + Rainy Shower Tap+ Solid Oak Worktop + Cabinets + Wc + Shower Sink + Shower Tempered Glass |
| Stairs | Illuminated Wooden Stairs for Access to Loft |
| Electrical & Water Systems | Electrical System: NHXM Halogen Free 3×6, 3×2.5, 3×1.5 Antigron Cables, Protective Corrugated Conduits For Cables, Switches And Sockets, Circuit Breakers And Residual Current Devices (Rcd), Tv Wall Mount Bracket, Earthing Rod, Electrical Installation Planning, Air Conditioning Infrastructure. Plumbing System: Ppr And Pprc Clean Water And Waste Water Installation. |
| Lighting | Interior Spot and Led Lighting, Bedside Wall Lights, Exterior Wall Sconce Lighting |
MB9 Catwalk Tiny House Belgium Plan
The MB9 Catwalk Tiny House measures 900 cm in length and 255 cm in width, making it fully compliant with tiny house regulations while providing a surprisingly spacious interior. This MB wheeled tiny house includes two loft floors, one bathroom, one kitchen, and a comfortable living area, all thoughtfully designed for maximum efficiency and usability.
Model Details
Updated on Şubat 24, 2026 en 10:45 am- Model: MB9 Catwalk
- Price: Get a Quote for Pricing
- Tiny House Size: 36 m2
- Bedrooms: 2
- Kitchen: 1
- Bathroom: 1
- Living Room: 1
- Plan: 3 Different Layout
- Type: Current Model
Features
- Kitchen Equipments: Include
- Kitchen Cabinet: Include
- Bathroom Equipments: Include
- Bedroom Wardrobe: Include
- Bathroom Cabinet: Include
- Interior and Exterior Lighting: Include
- Sink, Faucet, Toilet, Shower Cabin: Include
- Air Conditioning Infrastructure: Include
- TV Infrastructure and Mounting Bracket: Include
- Electrical and Water Installation Infrastructures: Include
- User Manuel: Available
Promotional Video
Tiny House Energy Consumption
- Energy Class: A+
- Monthly Average Consumption:
- Number of Pluggable Solar Panels: 7
- Solar Panel Power: 660W
- Maximum Solar Panel Installed Power: 4,62 kW
-
| Energy Class A+A+
- A
- B
- C
- D
- E
- F
- G
- H
