MB9 2+1 Tiny House
2
1
1
1
30Model Features
The MB9 2+1 Tiny House is a modern tiny house model that offers a perfect solution for those seeking compact living spaces. Its 2+1 configuration includes a master bedroom, an additional loft, and a functional living area, providing a spacious and comfortable living environment. With a contemporary aesthetic, this tiny house combines comfort and functionality through efficient space management. The interiors are designed to feel open and are equipped with modern details, focusing on energy efficiency. This structure stands out as an ideal choice for both everyday living and holiday getaways.
| Overall Dimensions | 9.00 x 2.55 m + Loft | 4-6 People |
| Chassis and Axle | Chassis: ST37 steel quality main chassis with double 100 NPU beams, ST37 steel intermediate cross members to prevent bending, and ST37 upper chassis. Axle Assembly: Dual axle system with brake system, 3,500 kg load capacity, braked coupling, 4 stabilizer jacks, 1 front support jack, side marker lights, tail lights, 4 tires and rims. |
| Frame | Galvanized Steel Profiles |
| Insulation | Rock Wool + XPS + Moisture Barrier + EPDM Membrane |
| Exterior Cladding | Thermowood Pine + Aluminum Panels |
| Interior Cladding | Laminated Wood Cladding or Birch Plywood |
| Flooring | Laminate Flooring + 18 Mm Plywood + Rock Wool + XPS + Polycarbonate |
| Roof | Plywood + Rock Wool + XPS + EPDM Membrane + Aluminum Panels |
| Doors and Windows | Thermally Insulated Tempered Double-Glazed Glass + Aluminum Framed Windows And Doors |
| Kitchen | MDF and Acrylic Cabinets + Solid Oak Kitchen Countertop + Butler Sink + Sink Tap + Faucet |
| Bathroom | SPC Wall Panels + Sink + Sink Tap + Rainy Shower Tap+ Solid Oak Worktop + Cabinets + Wc + Shower Sink + Shower Tempered Glass |
| Stairs | Illuminated Wooden Stairs for Access to Loft |
| Electrical & Water Systems | Electrical System: NHXM Halogen Free 3×6, 3×2.5, 3×1.5 Antigron Cables, Protective Corrugated Conduits For Cables, Switches And Sockets, Circuit Breakers And Residual Current Devices (Rcd), Tv Wall Mount Bracket, Earthing Rod, Electrical Installation Planning, Air Conditioning Infrastructure. Plumbing System: Ppr And Pprc Clean Water And Waste Water Installation. |
| Lighting | Interior Spot and Led Lighting, Bedside Wall Lights, Exterior Wall Sconce Lighting |
MB9 2+1 Tiny House Turkey Layout Plan
Our MB9 2+1 Tiny House model is 900 cm in length and 255 cm in width. The MB2+1 Tiny House on wheels includes 1 loft, 1 bathroom, 1 kitchen, 1 bedroom, and a living room. The model is designed for easy portability and movement, and it can accommodate 4-6 people.
Model Details
Updated on Mart 3, 2026 en 7:52 am- Model: MB9 2+1 Tiny House
- Price: Get a Quote for Pricing
- Tiny House Size: 30 m²
- Bedrooms: 2
- Kitchen: 1
- Bathroom: 1
- Living Room: 1
- Number of People: 4-6
- Plan: 3 Farklı Yerleşim
- Type: Current Model
Features
- Kitchen Cabinet: Available
- Bedroom Wardrobe: Available
- Bathroom Cabinet: Available
- Interior and Exterior Lighting: Available
- Sink, Faucet, Toilet, Shower Cabin: Available
- Air Conditioning Infrastructure: Available
- TV Infrastructure and Mounting Bracket: Available
- Electrical and Water Installation Infrastructures: Available
Promotional Video
Tiny House Energy Consumption
- Energy Class: A+
- Monthly Average Consumption: 150.00 kWh
- Maximum Monthly Lighting Consumption: 30.00 kWh
- Number of Pluggable Solar Panels: 5 Adet
- Solar Panel Power: 500 W
- Maximum Solar Panel Installed Power: 2.5 kW
-
150.00 kWh | Energy Class A+A+
- A
- B
- C
- D
- E
- F
- G
- H
